Ürünler PI - Air Bearings & Stages

PI - Air Bearings & Stages

When vibration-free motion, a high degree of velocity constancy, and the best possible angular repeatability are required, air bearing stages are used.

With air bearings, backlash, wear, and friction are all avoided. Precision PIglide linear, rotary, and spherical bearings can be motorized, integrated, and used in OEM, industrial, and research applications.

When very consistent velocity control, vibration-free motion, angular repeatability, and ideal geometric performance are required, air bearings outperform mechanical bearings. A thin air layer replaces mechanical contact in air bearing stages, preventing the effects of wear, friction, vibration, and hysteresis. XY air bearing tables, rotary tables and spindles, tip-tilt stages, and 3-degree-of-freedom spherical air bearings are among the products offered by PI. Solutions for 1, 2, 3, 4, 5, and 6 axis air bearings are provided using combinations of linear and rotary stages.

Applications for Miniature Air Bearing Stages

The A-142 air bearing miniature linear stage is ideally suited for high-precision motion applications, such as metrology, photonics alignment systems, optics positioning, and scanning. The noncontact design is ideal for cleanroom applications.

Linear Stages with Air Bearings

The A-142.010A1 miniature air bearing linear slide provides high speed and resolution with a direct drive voice coil motor and high precision linear encoder. A-142 PIglide Voice Coil Linear Stage with Air Bearings High Performance • Cleanroom-Compatible • Option for Vertical Mounting
A-131 PIglide VC Voice Coil Linear Stage with Air Bearings High-Performance Miniature Nanopositioning System
A-110 PIglide LC Linear Stage with Air Bearings Inexpensive High Performance Nanopositioning Stage
A-141 PIglide MB Miniature Linear Stage with Air Bearings High Performance, Cleanroom Compatible, Customizable
A-123 PIglide AT3 Linear Stage with Air Bearings High Performance Nanopositioning Stage
A-121 PIglide AT1 Linear Stage with Air Bearings High Performance Small Footprint Nanopositioning Stage

XY Stages with Air Bearings

A-351 MGS gantry system A-351 MGS Gantry System with Linear Motors Robust Compact Design with Recirculating Ball Bearing Guides for High Load Capacity.
A-341 PIglide HGS Hybrid gantry system A-341 PIglide HGS Hybrid Gantry System Hybrid Guide Design with Air Bearings and Recirculating Ball Bearing Guides for High Precision with Low Profile.
A-322 Base A-322 PIglide HS Planar Scanner with Air Bearing XY Positioning System with 1 nm Resolution
A-311 PIglide IS Planar Scanner with Air Bearing High-Performance, Compact XY Nanopositioning System

Rotation and Tip/Tilt Stages with Air Bearings

A-523 PIglide High-Precision Z Tip/Tilt Stage with Air Bearings High Performance • Cleanroom-Compatible • Low Profile
A-688.A100 A-68x PIglide RLA Rotation Stage with Air Bearings, Large Aperture Friction-free, Motorized
A-63x PIglide RL Flat Rotation Stage with Air Bearing Friction-free, Motorized
A-62x PIglide RM Rotation Stage with Air Bearings Friction-Free, Ideal for Indexing, Positioning, Scanning, Measuring Technology

PIglide Motion Controllers

A-811.CE PIglide Motion Controller for One Axis For Stages with Direct Drive, TCP/IP Interface
A-824 A-82x PIglide Motion Controller for 4, 6 or 8 Axes For Stages with Direct Drive and High Power Requirements, TCP/IP Interface
A-81x PIglide Motion Controller for 1, 2 or 4 Axes For Stages with Direct Drive, TCP/IP Interface

Air Bearings

A-60x PIglide RT Rotary Air Bearing Module Frictionless, Nonmotorized
A-10x PIglide RB Linear Air Bearing Module Friction Free, Ideal for Positioning, Scanning, Metrology
A-65x PIglide HB: Hemispherical Air Bearing Module Friction-Free, Ideal for Rotational Motion on Three Axes
